EJ20/EJ25 (IMPREZA/WRX/STI/GC8-GDB)
Flange : Std SUBARU Single Scroll
Actuator : 0.2~2 BAR
APPLICATIONS :
2002 - 2007 Subaru WRX
2004 - 2018 Subaru Sti
Replacement for : Stock TD04L Turbo P/N 49377-04100, 49377-04200, 49377-04300, etc.
*Stock MHI TD04L Turbo MAX 230HP
●Both Journal Bearing and Bolt-on Ball Bearing are Available to select from.,and please contact ZAGE for more information.
*** ZAGE can ship worldwide with no minimum order quantity. ***
|
Max HP |
Turbine Wheel |
AR |
Compressor Wheel |
CFM |
|
260+ |
TD04H ( 44.2/52mm - 6cm² ) |
41 |
19T ( 46/58mm ) |
450 |
|
250+ |
TD04L ( 41.2/47mm - 6cm² ) |
41 |
19T ( 46/58mm ) |
450 |
|
240+ |
TD04H ( 44.2/52mm - 6cm² ) |
41 |
13T ( 40.8/56mm ) |
|
|
240+ |
TD04L ( 41.2/47mm - 6cm² ) |
41 |
13T ( 40.8/56mm ) |
